Multifunction dosing pump VMF0706FP View larger

Multifunction dosing pump VMF0706FP + liter counter 1/2 140 I / L assembled on panel

EM11214131

New product

Pre-assembled marine wood panel comprising:

Multifunction dosing pump VMS MF flow rate 6 liters / h pressure 7 bar 220 Volts
Flow meter for hot water 140 pulses / liter ½ '' fittings
Connection pipes

The VMF pump coupled to the liter counter is the ideal solution for those who need a prewash system ready to use, easy to use and do not need any work or technical modifications

More details

549,96 € tax excl.

More info

The VMS MF electromagnetic dosing pump is the ideal solution for medium dosing requirements. Vertical mounting, it is equipped with a backlit LCD display and microprocessor control.

The hydraulic parts are made of PVDF, but on request it is also available with pump body and accessories in PP and PE pipe. The pump body is available, optionally, with manual bleeding or self-purge. The VMS MF, with constant or proportional dosing, has level control and the following functions: multi-function, setting of maintenance dosage in the event of plant standstill and pause-work mode.

FUNCTIONS

MULTIFUNCTION (Constant - Divide - Multiply - PPM - Batch - Volt - mA -% - ml / q)  Setting the MAINTENANCE DOSAGE in the event of a plant standstill.  PAUSE-WORK mode: cyclic dosage also adjustable by an external contact.

ACCESSORIES  injection valve in PVDF  PVDF level probe  foot valve / filter in PVDF  2 meters of suction hose (flexible PVC)  2 meters of air exhaust pipe (4x6 PVC)

Data sheet

ManufacturerEmec
