Fleck 9000/1600 mechanical 1 "Brass Meter 20 mc

WLFL90001610

New product

Industrial valve with Bronze body for softening applications with alternating service and immediate volumetric regeneration. Operation is completely managed by the fully programmable electronic board.

• Regeneration with softened water
• Start of Volumetric regeneration: Immediate

More details

1 480,00 € tax excl.

More info

Technical features
• Operating range Val "valve: 1bar dP - 4.0 m³ / h
• Operating range 1 "valve: 1bar dP - 4.7 m³ / h
• Backwashing capacity 1.8 bar dP - 1.9 m³ / h
• Input / output connections: ¾ "or 1"
• Cylinder connection: 2 "½ 8 NPSM
• Operating Pressure: min 1.8 bar - max 8.5 bar
• Operating Temperature: min 4 ° C - max 43 ° C
• Supply voltage: 230 - 24VAC transformer
• Power frequency: 50 Hz
• Valve body material: Bronze
• 6 "-16" softening bottle (1600)


Accessories included in the Supply
• Distributor tube Ø 27 x 1600 mm - Code ARI00365
• Ø 27 Bottom Diffuser - Code ARI00355
• 1 " brass yoke - Code FLA13398-10
• Air Check 3/8 "- Code FLA18168

Download

Scheda tecnica valvole Fleck

Download (1.23M)
