> >Adhesive heater resistance 25x18 cm 220V 150W double insulation 50 cm of cable
Adhesive heater resistance View larger

Adhesive heater resistance 25x18 cm 220V 150W double insulation 50 cm of cable

EL 25x18 220V

New product

XMAT heating elements are made by interposing a resistive circuit (resistance) between the layers of Polyester. Consequently, elements with thin and particularly flexible thicknesses suitable and suitable for heating any type of flat or curved surface are obtained. Possibility of integrating sensors or thermostats.

More details

46,50 € tax excl.

More info

Features:

  • Size 25x18 cm.
  • Power supply 220 V.
  • Absorption 150 W
  • Max working temperature 110 ° C
  • Max temp. With 105 ° C adhesive
  • Peak temperature max. 130 ° C
  • Typical Thicknesses (μm) 250
  • Typical flat dimensions 3000 x 600
  • Bending radius approx. 8 mm
  • Maximum load 6 kg / cm2

Advantages:

  1. Flexibility and lightness.
  2. Fixings by direct adhesion, hooks, velcro, vulcanization.
  3. Temperature / power differentiation on the surface.
  4. Integration of sensors.

Download

Resistenza riscaldatore adesivo

Download (1.07M)
