Flow meter 4 imp / L hot water 1/2 "

GI407080

New product

Single jet counter, direct reading

DRY dial for turbid and highly calcareous waters, with 360 ° rotating dial and, on request, with or without lid, with or without squeegee.
Models USF R80 DN 15 and DN 20, temperature classes T30 and T50, measuring range R80
Models USC R80 DN 15 and DN 20, temperature classes T70 and T90, measuring range R80

More details

116,17 € tax excl.

More info

Models USF-SA R80 DN 15 and DN 20, temperature classes T30 and T50, measuring range R80, with system for compensating the increase in water volume in case of frost
U0-D0: no straight pipe sections are required upstream and downstream of the meter
All models are MID approved according to the current Directive (module B + D), in compliance with EN 14154 and OIML R49
All models are certified for use with drinking water according to the D.M. 174
All the models, on request, can be supplied with a pulse emitter or with the only preparation for remote reading

FEATURES

DN gauge mm - inches 15 - 1/2
Q3 Permanent flow rate m³ / h 2,5
Q4 Overload flow rate m³ / h 3,125

Q2 Transition range with measuring range R80 [MPE ± 2%] l / h 50

Q1 Minimum flow with measuring range R80 [MPE ± 5%] l / h 31.25

S Sensitivity with measuring range R80 l / h 7
Accuracy class 2 2
ΔP Pressure loss class bar 0.63

MAP Maximum permissible operating pressure bar 16
Display range of the minimum / maximum quadrant m³ 0.0001 / 100.000 - 0.0001 100.000

A Length of the counter without fittings mm 110-80
Length of the counter with fittings mm 190-160

B Maximum space diameter mm 72
C Height with open lid mm 138
D Height in execution without cover mm 70
E Height at the tube mm 16

Weight with fittings kit kg 0,660
Weight without fittings kit kg 0,500

Data sheet

ManufacturerGioanola
