ODE 2 1/2 way solenoid valve body (NBR) NC in brass View larger

ODE 2 1/2 way solenoid valve body (NBR) NC in brass

ODE4

New product

Solenoid valvewith indirect action suitable for interception of fl uids
compatible with construction materials.
A minimum operating pressure of 0.1 bar is required.

More details

64,01 € tax excl.

More info

Connections G 1/2
Material Brass
Type Solenoid valves General Applications
Functionality 2-Way Indirect Drive
Flow rate Kv (l / min) 20, 25, 35, 45, 50
Pressure (M.O.P.D.) up to 20 bar

Applications Water, Air, Car Wash, Industrial Automation, Industrial Washing, Packaging, Thermoregulation, Water Treatment

Brass body - UNI EN 12165 CW617N
Welded tube AISI 300 series stainless steel
Fixed core AISI 400 series stainless steel
Mobile core AISI 400 series stainless steel
Copper displacement ring - Cu 99.9%
AISI 300 series stainless steel spring
Standard Shutter: V = FKM
On request: B = NBR E = EPDM
Brass Orifice - UNI EN 12165 CW617N

Data sheet

ManufacturerOde
