VS160 safety valve High pressure

- Brass central body.
- Internal details in stainless steel.
- Fully protected moving parts.
- Drain with integrated rubber door.
- Safe intervention with discharge of the entire flow.

TECHNICAL SPECIFICATIONS
Maximum flow 14 l / min - Maximum temperature 90 ° C (1)
NOMINAL PRESSURE 140-14 bar - MPa
PERMITTED PRESSURE 160-16 bar - MPa
MINIMUM ADJUSTABLE PRESSURE 14-1.4 bar - MPa
(2) PRESSURE INCREASE As VS 20-2 bar - MPa
ENTRY G ¼ M
BYPASS M G 1/8 F D. 13 mm
MASS g 135

(1) The valve has been designed for continuous use at a water temperature of 60 ° C. It can resist for short
periods at a maximum temperature of 90 ° C.
(2) Pressure increase = it is the pressure increase necessary to the valve, to discharge the maximum flow rate with
calibration at maximum pressure.
