> >>Fleck 9000/1600 3/4 "Meter 8mc + extension 40 mc
Fleck 9000/1600 3/4 View larger

Fleck 9000/1600 3/4 "Meter 8mc + extension 40 mc

WLFL90001606

New product

Industrial valve with Bronze body for softening applications with alternating service and immediate volumetric regeneration.

• Regeneration with softened water
• Start of Volumetric regeneration:

Immediate Technical features
• Operating range Val "valve: 1bar dP - 4.0 m³ / h
• Operating range 1 "valve: 1bar dP - 4.7 m³ / h
• Backwashing capacity 1.8 bar dP - 1.9 m³ / h

More details

1 273,05 € tax excl.

More info

• Input / output connections: ¾ "or 1"
• Cylinder connection: 2 "½ 8 NPSM
• Operating Pressure: min 1.8 bar - max 8.5 bar
• Operating Temperature: min 4 ° C - max 43 ° C
• Supply voltage: 230 - 24VAC transformer
• Power frequency: 50 Hz • Valve body material: Bronze
• 6 "-16" softening bottle (1600)

Accessories included in the Supply
• Distributor tube Ø 27 x 1600 mm - Code ARI00365
• Ø 27 Bottom Diffuser - Code ARI00355
• 1 "brass yoke - Code FLA13398-10
• Air Check 3/8 "- Code FLA18168

Download

Scheda tecnica valvole Fleck

Download (1.23M)
