> >>Pump CWX 1810 Right 18 liters 100 bar
CWX 1810 Right Pump View larger

Pump CWX 1810 Right 18 liters 100 bar

AR CWX 1810

New product

Alternative 3-piston volumetric pumps for use on washing systems. Pump body and covers in die-cast aluminum (cast iron for the RTF series). Nickel-plated stamped brass head for better protection and resistance in medium aggressive atmospheres. Piston movement achieved through the rod-crank system.

More details

1 055,00 € tax excl.

More info

Connecting rods in special die-cast zinc-aluminum alloy with anti-friction or bronze properties (RCW and RTF series). Double seal sealing system able to minimize any water leaks. Molded and heat treated steel shaft to ensure high mechanical strength. High quality bench bearings compared to the required standards.

Right attack CWX pump
Capacity 18 liters per minute
Max pressure 100 Bar
Max power 5.5 hp
Turns 1200 minutes
Weight 16 kg

Data sheet

ManufacturerAnnovi Reverberi

Download

Pompa CWX 1810 Destra

Download (180.68k)
