Construction in nickel-plated brass, stainless steel arms. Frontal rotating seals in high resistance ceramic material. Axial forces balance to minimize wear. Rotation on stainless steel ball bearings. Ball bearings protected against water infiltration. High performance and long life. Number and length of the arms variable on request
Share on social :
Width 210 mm – 8.26 in
Entry G 3/8 M
Output 2 × 1/8 Npt F
Mass 759 gr – 26.77 oz
Nominal pressure 350 bar – 35 MPa – 5100 psi
Permitted pressure 390 bar – 39 MPa – 5650 psi
Nominal flow 40 l / min – 10.5 USGpm
Nominal temperature 120 ° C – 250 ° F
Maximum working temperature 0-90 ° C – 32-195 ° F
| Weight | 1 kg |
|---|---|
| Produttore |
